quality PCAP Touch Panel & Touch Screen Panel factory

Industry Background: Evolution and Pain Points of Touch Control Technology With the popularization of intelligent interactive devices in the fields of education, healthcare, and commercial display, the market demand for medium-sized touch all-in-one PCs (21.5“-32”) is surging. However, traditional touch solutions are facing three major bottlenecks: IN CELL: superior performance but high cost, complex process leading to low yield (about 75%), squeezing the profit margin of the whole machine. GFF/GG: Controllable cost but thick module (more than 1.8mm), wide bezel (≥6mm), additional modification of equipment structure, long adaptation cycle. Lack of standardization: Manufacturers often need to customize and develop, with a long delivery cycle, making it difficult to respond quickly to market demand. Against this background, FINELINK has launched OGF (One Glass Solution with Film) integrated touch module based on 14 years of capacitive touch technology accumulation to break through the industry dilemma with technological innovation.   OGF technology analysis: why has it become a new standard in the industry? 1. Structural Innovation: Integrated Design to Reduce Cost and Increase Efficiency OGF adopts the integrated lamination process of “Glass + Touch Sensor + Optical Adhesive”, compared with traditional solutions: De-redundant structure: reduce 2-3 layers of film stacking, module thickness compression to 0.95mm, cost reduction of 30%-40%. Process optimization: Through vacuum lamination and intelligent inspection technology, mass production yield is increased to over 95%, and the delivery cycle is shortened to 70% of the industry average. 2. Optical performance breakthrough: eye protection and display at the same time Etching AG process: Micron-level etching treatment on the surface, reflectivity ≤ 2%, light transmission rate ≥ 92%, and the screen is clearly visible under strong light conditions. Full lamination technology: OCA optical adhesive is used to fill in, eliminating the reflection of the air layer and enhancing the transparency of the display. 3. Precise adaptation: standardized compatibility with mainstream devices Full Size Coverage: Support 21.5“, 23.8”, 24.5“, 27”, 32” five mainstream specifications, compatible with more than 90% of Del, Lenovo, Asus and other brands. Interface pre-compatible: support USB/I2C protocol, seamless connection with mainstream touch IC, shorten development cycle.   OGF's four core advantages 1.Dimension Technical Performance User Value 2.Cost 40%-50% lower than the cost of IN CELL Save 80,000-150,000 RMB in mold modification fee for a single project. 3.Design 0.95mm thickness + 3.3mm ultra-narrow edge, screen-to-body ratio increased to 92.5% to help high-end equipment, lightweight design 4.Performance: Touch accuracy ±0.5mm, response time ≤8ms, medical-grade precision operation, smooth writing in educational scenarios.   Why choose FINELINK? Manufacturing strength: 30,000 square meters fully automated production base, 12 production lines with an annual capacity of 15 million pieces, 48-hour emergency response. Technology accumulation: 37 core patents, covering the whole chain of touch IC design, AG etching and optical lamination. Quality Assurance: IATF 16949 automotive grade quality control system, 18 inspection processes. Service Commitment: 7-day delivery of customized samples, 3-year warranty, remote/offline technical support.

As the Lantern Festival illuminates the night sky, we at Finelink Optoelectronics would like to extend our warmest wishes to our valued customers, partners, and friends around the world. May this festival of lights bring you joy, prosperity, and endless happiness! Grateful for Your Trust and Support Since our establishment in 2010, Finelink Optoelectronics has been dedicated to the research, development, and manufacturing of capacitive touch screens. With 13 years of technical expertise and a 30,000㎡ modern production base, we have provided high-quality OGF integrated touch solutions for a wide range of applications, including all-in-one PCs, educational devices, and commercial displays. Your trust and support have been the driving force behind our continuous innovation and growth. Lantern Festival Wishes On this special day, symbolizing reunion and hope, we wish you: A life as sweet as the traditional glutinous rice balls (tangyuan)! A career as vibrant and colorful as the festive lanterns! A future as bright and promising as the full moon! Contact Us In the new year, Finelink Optoelectronics remains committed to delivering exceptional products and services. We look forward to continuing our journey of success together. If you have any inquiries or collaboration opportunities, please feel free to reach out to us! Website: https://cn.finelink-china.com Contact: Mr. Xu +86 13816617953 #HappyLanternFestival #FinelinkOptoelectronics #Gratitude #ReunionAndHope #TouchScreenExpert Once again, we wish you a joyful Lantern Festival, filled with warmth, happiness, and prosperity!

FINELINK Optoelectronics Exhibits at the 19th China International Small and Medium Enterprises Fair (SMEF) From November 15 to 18, 2024, FINELINK made a wonderful appearance at the 19th China International Small and Medium Enterprises Fair (THE 19# CHINA INTERNATIONAL SMALL AND MEDIUM ENTERPRISES FAIR). The exhibition was held in Hall 14.3, Zone C, No. 380, Yuejiang Zhong Road, Guangzhou (Canton Fair Complex), and FINELINK's booth number was A07, which attracted a large number of visitors to pay attention to and communicate with each other. In this exhibition, FINELINK demonstrated the latest technology and solutions for 7-65 inch capacitive touch screen and fully laminated touch display module. As a high-tech enterprise specializing in touch screen manufacturing and customization services, FINELINK has gained wide acclaim on the exhibition site with its excellent technical strength and rich industry experience. Visitors not only showed great interest in FINELINK's products, but also actively inquired about the application scenarios and personalized customization solutions of the touch panel modules. FINELINK's booth was crowded with people and the atmosphere of interaction was warm. The company's team had in-depth communication with the exhibitors to further understand the customers' needs and discuss future cooperation opportunities. The exhibition provided an important platform for FINELINK to expand its market and strengthen its brand influence, and also opened a window for more customers to learn more about the company's innovative technologies. In the future, FINELINK will continue to focus on technological innovation in the field of touch display, provide efficient and reliable solutions for global customers, and promote the development of intelligent touch display industry.

Exciting News! FINELINK Secures Provincial Award Amid Fierce Competition From August 29 to 30, the finals of the 13th China Innovation and Entrepreneurship Competition (Hubei Division) were successfully held in Xianning. After intense competition, Hubei Finelink Optoelectronics Co., Ltd. (FINELINK) distinguished itself and won third prize, adding another accolade to the company’s achievements.   This year's competition, which began in June, was themed "Gathering for Innovation, Advancing Together." The event aimed to identify promising technology companies with strong potential, innovative business models, and advanced technology, thereby guiding more capital, talent, and innovation platforms toward these enterprises. The competition covered a wide range of emerging industries, including next-generation information technology, advanced equipment manufacturing, new materials, biomedicine, new energy, and energy conservation and environmental protection. A total of 977 outstanding entrepreneurial teams from across the province participated. After several rounds of selection, 397 companies advanced to the semifinals, 100 were awarded the Excellence Award, and 50 companies made it to the finals.   FINELINK stood out with its "OGF Touch Display Module Project," advancing to the finals and securing third prize. The company is currently the only high-tech enterprise in Hubei Province that integrates optical glass deep processing, FOG manufacturing, TP bonding, and full-lamination manufacturing in large-size touch screens. It is also a pilot demonstration enterprise for the integration of industrialization and informatization. Notably, FINELINK is the only company from Huanggang to have reached the finals and won an award in the past three years.   This achievement is not only a recognition of FINELINK’s innovative capabilities and technical strength but also provides fresh momentum for the company’s future development. FINELINK will continue to focus on technological innovation, promote industrial upgrades, and strive to contribute more to the industry’s growth.

FINELINK Successfully Participates in the 2024 Korea Display Exhibition From August 14 to 16, 2024, FINELINK successfully participated in the Korea Display Exhibition (KOREA DISPLAY EXHIBITION) held at COEX Hall, Seoul, Korea (513, Yeongdong-daero, Gangnam-gu, Seoul, Korea). The company's booth, located at B-10, attracted significant attention as FINELINK showcased its latest display technologies and products to a global audience. The event saw a large turnout of industry professionals who visited the FINELINK booth. The innovative display technologies and high-quality products exhibited by FINELINK were highly praised by attendees. Many customers and partners expressed strong interest in the products and showed a willingness to explore further collaboration opportunities. Through this exhibition, FINELINK not only demonstrated its leading technological capabilities but also strengthened its connections with global customers and partners, laying a solid foundation for future market expansion. FINELINK remains committed to driving innovation in display technology and providing superior solutions to its customers.

OGF Product Introduction: A Groundbreaking Upgrade Experience   OGF is the best upgrade product of OGS (One Glass Solution) technology, providing users with excellent cost performance and outstanding performance. As the best alternative to traditional In-cell modules, OGF leads the development of new generation display technology.       1. Superior price/performance ratio:   OGF products stand out for their excellent price/performance ratio. Compared to traditional In-cell modules, it achieves an ideal balance between performance and cost, ensuring high process yields while enabling users to better enjoy a high-quality display experience when upgrading without having to pay an exorbitant price.   2. Advanced OGS technology:   OGF products adopt advanced OGF technology, i.e. One Glass Film. comes with AG full lamination, standard AG surface treatment process, eye protection and anti-glare. This technology integrates the touch screen and display, making the whole structure simpler and thinner, while improving the touch sensitivity and display effect. Users will be able to experience clearer and more vivid images while enjoying more sensitive touch operations.   3. Ultra-thin design:   Compared to traditional In-cell modules, OGF products have a slimmer design. This makes the device lighter and more portable, providing users with a more comfortable carrying and operating experience. Not only that, the ultra-thin design also adds color to the overall appearance of the device, showing a more stylish appearance.   4. Good compatibility:   OGF products are replicated in 1:1 appearance size according to OC LCD glass, which has excellent compatibility and can be easily applied to a variety of devices, including smartphones, tablets and so on. This provides users with the possibility of more choices, whether it is to replace the screen of the existing equipment or new equipment upgrades, can be easily realized.   5. Medium size full coverage:   The company's existing OGF product sizes cover: 21.45", 21.5", 23.8", 24.5", 27", 32" and other sizes. The glass substrate is anti-scratch and anti-glare, and has independent intellectual property rights, the TP thickness is only 0.95mm, the narrow edge is only 3.3mm, to achieve the real borderless effect.   Overall, OGF products are the pinnacle of FINELINK's technological upgrades, and have become the best alternatives to traditional In-cell modules with their cost-effective, advanced technology, ultra-thin design, and good compatibility. By choosing OGF, you will usher in a superior display experience and a fashionable technological trend.

Hello, everyone! We're here at the booth of Hubei Panlitech Optoelectronics Co., Ltd., and we're thrilled to be part of the 2023 Hong Kong Consumer Electronics Expo. It's a four-day extravaganza where we're showcasing the cutting-edge optoelectronic technologies. First, let's take a look at our latest high-resolution OGF displays, which promise to deliver stunning visual experiences, whether on mobile devices or TVs. Here we have our wide range of touchscreens, which offer excellent energy-saving performance and are perfect for home and commercial use. In addition, we offer personalized optoelectronic solutions to meet the needs of different customers. A big thank you to all the visitors who have joined us! Your curiosity and questions have made this event even more vibrant. Whether you're looking for electronic products or exploring potential collaborations, we're here to share our expertise with you. The event has come to a successful conclusion, and we've established valuable connections with numerous attendees and potential partners. We look forward to bringing our innovative products to more markets and enhancing the consumer experience.



Optical bonding is a technique used in the electronics industry to enhance the performance of displays. It is a process of bonding a protective layer, such as glass or polycarbonate, directly to a display's surface using an optically clear adhesive. This technique can significantly improve the visibility, durability, and overall quality of displays. In this article, we will delve into the details of optical bonding and its benefits.   What is Optical Bonding?   Optical bonding is the process of attaching a protective layer, such as glass or polycarbonate, directly to the surface of a display. The bonding is done using an optically clear adhesive that eliminates the gap between the two surfaces, reducing the amount of reflection and refraction that occurs when light passes through them.   The technique is particularly useful for enhancing the readability and durability of displays used in harsh environments, such as outdoor displays, marine displays, or displays used in industrial or military applications. The bonding process provides a layer of protection against dust, moisture, and other environmental factors that could damage the display.   Benefits of Optical Bonding   Improved Readability: Optical bonding significantly reduces glare and reflection, improving the readability of displays in bright sunlight or other high ambient light conditions. The reduction in reflection also helps to enhance the contrast and color saturation of the display, making it easier to read and providing a more vibrant viewing experience.   Enhanced Durability: The protective layer provided by optical bonding helps to prevent scratches and other forms of damage to the display. This is particularly important for displays used in harsh environments where they may be subjected to extreme temperatures, humidity, and other environmental factors.   Increased Touch Sensitivity: Optical bonding improves the touch sensitivity of displays, making them more responsive to touch inputs. This is particularly important for applications that rely heavily on touch inputs, such as interactive kiosks, digital signage, or medical displays.   Improved Optical Performance: Optical bonding can help to reduce the amount of light loss that occurs when light passes through the display. This results in a brighter and clearer display, with improved contrast and color saturation.   Cost Savings: Optical bonding can reduce the need for additional components, such as anti-glare filters or backlight enhancements. This can help to reduce the overall cost of displays, making them more affordable for a wider range of applications.     Applications of Optical Bonding   Optical bonding is widely used in a variety of applications, including outdoor displays, industrial displays, medical displays, marine displays, and digital signage. It is particularly useful for displays used in harsh environments, where durability and readability are critical factors.   For example, outdoor displays used in high-traffic areas, such as airports, train stations, and shopping malls, benefit from optical bonding because it reduces the amount of reflection and glare from the surrounding environment. This makes it easier for people to read the displays and provides a more pleasant viewing experience.   Medical displays also benefit from optical bonding because it improves the clarity and readability of images, making it easier for medical professionals to make accurate diagnoses.   Conclusion   Optical bonding is a technique used in the electronics industry to enhance the performance of displays. It involves bonding a protective layer directly to the surface of the display using an optically clear adhesive. The technique provides a layer of protection against environmental factors and significantly improves the readability, durability, and overall quality of displays.   Optical bonding is widely used in a variety of applications, including outdoor displays, industrial displays, medical displays, marine displays, and digital signage. Its benefits include improved readability, enhanced durability, increased touch sensitivity, improved optical performance, and cost savings.

The company participated in the Hong Kong Consumer Electronics Exhibition from April 11-14, 2023 to showcase its latest products. During the exhibition, we displayed our newest products and services and engaged with global clients and partners to share our latest achievements. This exhibition provided an excellent opportunity to showcase our progress over the past year. Our R&D team has been committed to innovation and has introduced a series of cutting-edge products with leading technology. These products can help our customers improve efficiency, reduce costs, and enhance their business processes. We are proud to showcase these results and have received positive feedback and suggestions from various stakeholders. Through this exhibition, we have established relationships with more industry colleagues, and we will continue to deepen our presence in the touch screen industry and pursue innovation in the future.

Touch screen, also known as "touch screen", "touch panel", is an inductive LCD device that can receive input signals such as touches. As one of the latest computer input devices, the touch screen is currently the simplest, most convenient and natural way of human-computer interaction.   The first characteristic of a touch screen. Transparent, it directly affects the visual effect of the touch screen. Transparent degree of transparency, infrared technology touch screen and table + - surface acoustic wave touch screen is only separated by a layer of pure glass, transparent can be considered the best, other touch screen this point should be well pushed some, "transparent", in the touch screen industry, only a very general concept, many touch screen is a multi-layer composite film The second characteristic of the touch screen. Touch screen is an absolute coordinate system, to choose where to directly point that, and the mouse this type of relative positioning system is the essential difference between the intuitive once in place. The third characteristic of touchscreens. Detection of touch and positioning, a variety of touch screen technology is dependent on their own sensors to work, and even some touch screen itself is a set of sensors. The respective positioning principles and the respective sensors used to determine the speed of response, reliability, stability and life of the touch screen.

  The cover plate is a transparent lens attached to the outside of the electronic display screen and used to protect the touch display module of the touch display screen and the screen of the non-touch display screen. The touch module of the touch screen is a precision-processed sensitive component. If it is exposed to the outside, it will easily affect its use effect and life due to abrasion and scratches from sharp objects. water ripples, etc. Therefore, a cover plate needs to be added outside the display screen to protect the touch module and the display screen from damage. According to the material analysis of the cover plate substrate, the cover plate can be mainly divided into glass cover plate, ceramic cover plate, plastic cover plate and optical composite material cover plate: (1) Glass cover: Glass is a transparent semi-solid material with good light transmittance and special texture. After ion exchange, it can enhance the surface hardness and toughness. It is currently a widely used material in China's cover plate industry. (2) Ceramic cover: The light transmittance of the ceramic cover is poor, and it is mostly used in the rear cover. At the same time, the processing cycle of the ceramic cover plate is long, the process is difficult and the cost of input is high: (3) Plastic cover: Usually, acrylic material, namely polymethyl methacrylate (PMMA), is an early developed thermoplastic with good transparency and chemical stability, and acrylic material is cheap and easy to machine, but it is resistant to heat and acid and alkali resistance are poor. (4) Optical composite material cover: Optical composite materials are cover materials with optical functions based on multi-layer resin materials (PMMA.PC) as the base material. Compared with plastic materials, they have higher light transmittance and overcome the fragile nature of glass and ceramic materials. The shortcomings have become an important development direction of China's cover plate industry.

  Advantages: 1. Novel operation The capacitive touch screen supports multi-touch, making the operation more intuitive and interesting. 2. Not easy to touch by mistake Since the capacitive touch screen needs to sense the current of the human body, only the human body can operate it, and it will not respond when touched with other objects, so the possibility of accidental touch is basically avoided. 3. High durability Compared with resistive touch screen, capacitive touch screen has better performance in dustproof, waterproof and wear-resistant.   Disadvantages: 1. The accuracy is not high For technical reasons, capacitive touchscreens are less accurate than resistive touchscreens. Moreover, only fingers can be used for input, and it is difficult to recognize complex handwriting input on a small screen. 2. Susceptible to environmental impact When environmental factors such as temperature and humidity change, it will also cause instability or even false touch of the capacitive touch screen. For example, when a user moves his body close to the screen while using it, it may cause drifting, and even operating in a crowded crowd may cause false touches. 3. High cost In addition, the current capacitive touch screen still has certain technical difficulties in the step of attaching the touch panel to the LCD panel, and the yield is not high, so the cost of the capacitive touch screen is also increased invisibly.

Optical Bonding has the following advantages compared with the traditional frame sticking (mouth glue sticking) method:   1. Better display effect. Optical Bonding technology eliminates the air between the screens, which can greatly reduce light reflection and reduce the loss of transmitted light, thereby increasing the brightness and enhancing the display effect of the screen. 2. The screen is isolated from dust and water vapor. The air layer of the ordinary bonding method is easily polluted by dust and water vapor in the environment, which affects the use of the machine; while the OCA glue of Optical Bonding fills the gap, the display panel is closely attached to the touch screen, and dust and water vapor have nowhere to enter, maintaining the screen of cleanliness.     3. Reduce noise interference. In addition to improving the strength of the touch screen and the display panel, Optical Bonding can effectively reduce the interference caused by noise to the touch signal, and improve the smoothness of the touch operation. 4. Make the body thinner. The Optical Bonding screen has a thinner body, and the touch screen and the display are bonded with optical glue, which only increases the thickness of 25-50μm; it is 0.1-0.7mm thinner than the ordinary bonding method. The thinner module thickness provides greater flexibility for the structural design of the whole machine, and the thinner body improves the product quality and highlights the technical content.     5. Simplify assembly. The assembly of the Optical Bonding module and the whole machine can be directly fixed by means of snaps or locking screws, which reduces the assembly problems caused by the bonding deviation, and simplifies the assembly process and reduces the assembly cost. The Optical Bonding module does not need to consider the protection of dust and water vapor, and can achieve a narrower frame. At the same time, because it does not need to consider the double-sided bonding strength, it also contributes to the design of a narrow.

  How resistive touch screen works       The part of the screen body is made of a composite film that matches the surface of the display, the base layer is plexiglass or a layer of glass, the outer part has a conductive layer, and there is a hardened rough surface layer on top. When the user's hand touches the screen, there will be a contact at the touch point, which are two conductive layers that are usually insulated from each other. One of the conductive layers is connected to the voltage scene in the y-axis direction. At this time, the voltage of the detection layer changes from zero to non-zero. During this switch-on process, the controller has detected and then switched between them. This can also be said to be the same basic principle of all resistive touch screens.​​​​   How capacitive touch screen works       Usually, there is a sense of electric current in the human body, and it is only by using this point that we can work. It is composed of two double-layer composite glass screens, which are coated with a layer of ITO in the glass layer and in the middle of its interlayer. The outer layer is a protective layer of glass, and the ITO layer in the middle of the interlayer is used as a working surface. When the user's finger touches the metal layer, in the presence of the electric field of the human body, the user and the surface of the touch screen will combine into a capacitor, which is a direct conductor. The capacitive controller can accurately calculate where the touch point is through the ratio of the current.​​   How infrared touch screen works     The principle of the infrared touch screen is to use the infrared matrix in two different directions of y and x to accurately locate and monitor the touch position of the user. The outer frame of the circuit board is installed at the front end of the display, and then the circuit board cannot separate the infrared receiving tank and the transmitting tube around the screen. When the finger touches the screen, the two infrared rays intersecting at the position of the core will be directly blocked by the finger, so any position of the touch point on the screen can be accurately determined.

  Advantage: 1. There are no physical buttons, and software can also be used to achieve various operations, such as zooming in, moving, etc. 2. Multi-touch (more than two points) can realize various inputs such as zoom in and zoom out. 3. The displayed operation object is consistent with the input object, and has intuitive operability. 4. The integration of input and display can realize the miniaturization of the machine, and the degree of freedom of design is relatively high. 5. There will be no gaps like keyboards, switches, etc., entering garbage, dust, water, etc., not easy to damage, and easy to maintain.   Shortcoming: 1. Not suitable for keyboard, mouse, buttons and other fast input. 2. Direct touch display, the screen is easy to be polluted, and it is difficult to read the information; it is easy to cause misoperation due to scratches and so on. 3. There is no click like a button or a mouse, so the input action will become awkward (there is also a touch screen that can get a click). 4. It is difficult for the blind to use it, so it needs to be used together with voice instructions and buttons, or to specify the touch position.

    On October 14, 2021, the employees of FINELINK inspected capacitive touch screens and LCD screens in the intelligent dust-free purification workshop. The company's R&D team independently innovated 36 utility model patented technologies, which improved the compatibility of capacitive touch screen and liquid crystal display production equipment terminals. The products are widely used in home appliances, telecommunications, finance and optoelectronics enterprises, with an order output of 100,000 pieces per month Display supply and sales to domestic enterprises, production orders increased by 30% year-on-year.     FINELINK employees test capacitive touch screen and LCD screen in the intelligent dust-free purification workshop.

    On August 24, in the dust-free workshop of Hubei FINELINK, employees are rushing to make orders. The company's main products are medium and large size touch screens and intelligent interactive products, and it is an important supplier of Xiaomi, Hisense and other companies. At present, the company's products are in short supply, and orders have been placed until the end of the year. This year, it is expected to achieve an output value of 120 million yuan.
