Product Description
The Industrial 15" Projected Multi-Touch Waterproof Capacitive Touch Screen Panel with EETI/ILITEK Controller is engineered for high-performance and reliability in demanding industrial environments. Combining advanced touch technology with a robust waterproof design, this panel ensures precise and responsive touch interaction even in challenging conditions. Ideal for various industrial applications, this touch screen panel is equipped with EETI/ILITEK controllers for seamless integration and optimal performance.
| Item |
PCAP 15 15.6 17 18.5 19 19.5 23.6 23.8 24 27 32 43 55 inch Large I2C PCAP Capacitive Touch Switch Screen Panel |
| Ratio |
5:4/4:3/16:9 |
| Structure |
G+G |
| Type |
Capacitive |
| Touch controller |
EETI/ILITEK |
| Connection |
COB |
| Cover glass(T) |
1.1/2/3/4/5/6 mm |
| SENSOR(T) |
0.7/1.1 mm |
| Surface hardness |
≥6H |
| Transmittance |
≥85% |
| Touch points |
10 Points |
| Operating Temperature |
-20℃~+60℃ |
| Interface Type |
USB,RS232,I2C |
| Color |
Black,White,Transparent,colors optional |
| Customized |
AG/AG/AF/AM/AH/Waterproof/Glove touch |
| Operating system |
WinXP/7/8/10,Android,IOS,Mac,Linux |
| Application |
Industrial,medical,banking,consumer,military,education,HMI.... |
| Warranty |
12 Months(3 years maximum) |
Product Features
- Projected Capacitive Touch Technology: Provides accurate and responsive multi-touch capabilities, supporting up to 10 touch points.
- Waterproof Design: IP65-rated, offering excellent protection against water and dust ingress, suitable for harsh environments.
- Durable Construction: Made with industrial-grade materials to withstand tough operating conditions and frequent use.
- EETI/ILITEK Controller: Ensures compatibility and high performance with reliable touch control.
- High Brightness and Clarity: Features a high-brightness display with anti-glare properties for clear visibility in various lighting conditions.
- Wide Operating Temperature Range: Capable of functioning efficiently in extreme temperatures, making it suitable for diverse industrial settings.
Application Scenarios
- Industrial Automation: Enhances the efficiency and interactivity of control systems in manufacturing and processing plants.
- Outdoor Kiosks: Ideal for interactive kiosks in outdoor environments due to its waterproof and durable design.
- Public Information Systems: Suitable for public information displays in transport hubs, shopping centers, and other public areas.
- Healthcare: Perfect for medical equipment interfaces that require high reliability and easy sanitation.
- Retail and Hospitality: Used in point-of-sale systems and self-service terminals, providing a robust and user-friendly interface.
Customization Services
- Size and Specifications: Customizable dimensions and technical specifications to meet unique project requirements.
- Touch Sensitivity: Adjustable touch sensitivity settings to cater to different user needs and applications.
- Branding and Design: Options for custom branding and design to align with your company's visual identity.
- Additional Protection: Available enhancements such as vandal-resistant glass and anti-reflective coatings for added durability.
- Software Integration: Custom software solutions and integration services for seamless operation with your existing systems.
Packaging and Shipping
- Secure Packaging: Each unit is packaged securely to prevent damage during transit.
- Custom Packaging: Tailored packaging solutions are available to meet specific branding and logistical needs.
- Global Shipping: Reliable and efficient shipping services to ensure timely delivery worldwide.
- Eco-Friendly Materials: Use of environmentally friendly packaging materials to minimize environmental impact.
FAQ
Q: Is this touch screen panel suitable for all weather conditions?
A: Yes, the panel is IP65-rated, providing protection against water and dust, making it ideal for use in various weather conditions.
Q: How many touch points does this panel support?
A: The panel supports up to 10 simultaneous touch points, providing a responsive and interactive experience.
Q: Can the touch screen be customized to fit my specific application?
A: Yes, we offer customization services to tailor the touch screen’s size, specifications, and design to meet your specific requirements.
Q: What type of content can be displayed on this touch screen panel?
A: The panel supports a wide range of multimedia content, including videos, images, and interactive applications.
Q: How do I install the touch screen panel?
A: The panel comes with detailed installation instructions and necessary mounting hardware. Professional installation services are also available if needed.
Q: What is the warranty period for this product?
A: The product comes with a standard one-year warranty, with options for extended warranties available.
Q: Is technical support available for setup and integration?
A: Yes, comprehensive technical support is available to assist with the setup and integration of the touch screen panel.
Q: Can this panel be used in bright sunlight?
A: Yes, the panel features high brightness and anti-glare properties, ensuring clear visibility even in direct sunlight.
Q: What controllers are compatible with this touch screen panel?
A: The touch screen panel is equipped with EETI/ILITEK controllers, ensuring compatibility and high performance.
