10.1 Inch Touch Screen Panel PCAP Interactive Touch Screen Display

10.1 Inch Touch Screen Panel PCAP Interactive Touch Screen Display

Touch Screen Panel PCAP

PCAP Interactive Touch Screen Display

10.1 Inch Interactive Touch Screen Display

Place of Origin:

China

Brand Name:

FINELINK

Model Number:

FLK8059101

Contact Us
Request A Quote
Product Details
Application:
Touch Monitor
Interface:
USB/I2C/Serial Port
Type:
Capacitive
Diagonal Screen Size:
16:9
Drive IC:
ILITEK/EETI/SIS
Highlight:

Touch Screen Panel PCAP

,

PCAP Interactive Touch Screen Display

,

10.1 Inch Interactive Touch Screen Display

Payment & Shipping Terms
Minimum Order Quantity
2 pieces
Price
$13.07/pieces 2-99 pieces
Packaging Details
2024 Hot-Sale FINELINK Brand 10K Month Capacity 10.1 Inch G+G EETI/ILITEK Kapazitives Touchpanel PCAP
Standard packaging with carton or wooden box
1.The touch panel packing with foam plastic materials;
2.Packing with carton or wooden box.
Delivery Time
7-20 work days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
1000000 Piece/Pieces per Month 21.5 Inch Touch Panel for example
Product Description

Product Description

The 10.1 Inch Touch Screen Panel PCAP Interactive Touch Screen Display is a cutting-edge solution designed for various interactive applications. Utilizing advanced Projected Capacitive (PCAP) touch technology, this display offers exceptional accuracy, responsiveness, and durability. Whether for commercial, industrial, or educational use, this touch screen panel delivers a superior user experience with its intuitive and interactive interface.

Item
10.1 inch Capacitive Touch Panel
Ratio
16:9
Structure
G+G
Type
Capacitive
Touch controller
EETI/ILITEK
Connection
COB
Lens OD
247*150mm
Sensor OD
222.5*125mm
Cover glass(T)
2mm
SENSOR(T)
0.7mm
Surface hardness
≥6H
Transmittance
≥85%
Touch points
10 Points
Operating Temperature
-20℃ ~ +60℃
Interface Type
USB, RS232, I2C
Color
Black,White,Transparent,Colors Optional
Customized
AG/AR/AF/AM/AH/Waterproof/Vandalproof/Glove touch
Operating system
WinXP/7/8/10,Android,IOS,Mac,Linux
Application
Industrial,Medical,Banking,Consumer,Military,Education,HMI.....
Warranty
12 Months(3 years maximum)

Product Features

  • Projected Capacitive (PCAP) Technology: Ensures highly accurate and responsive touch input, supporting multi-touch functionality.
  • 10.1 Inch Display: Provides a clear and vibrant visual experience with a perfect size for interactive applications.
  • Durable Design: Built to withstand frequent use and harsh environments with robust construction.
  • Wide Compatibility: Compatible with various operating systems, including Windows, Android, and Linux.
  • Multi-Touch Support: Recognizes multiple touch points simultaneously for a more interactive user experience.
  • High Resolution: Offers high-definition display quality with sharp and clear images.
  • Anti-Glare Coating: Reduces reflections and enhances visibility under different lighting conditions.

10.1 Inch Touch Screen Panel PCAP Interactive Touch Screen Display 0

Application Scenarios

  • Retail and Point-of-Sale (POS) Systems: Ideal for self-service kiosks, interactive displays, and checkout terminals.
  • Industrial Automation: Suitable for control panels, machine interfaces, and monitoring systems in industrial environments.
  • Healthcare Applications: Perfect for medical devices, patient monitoring systems, and diagnostic equipment.
  • Educational Tools: Great for interactive whiteboards, e-learning devices, and educational kiosks.
  • Hospitality Industry: Useful for interactive menus, check-in kiosks, and information displays in hotels and restaurants.
  • Transportation Hubs: Suitable for ticketing systems, information kiosks, and wayfinding displays in airports and train stations.

10.1 Inch Touch Screen Panel PCAP Interactive Touch Screen Display 1

Customization Services

  • Custom Dimensions: Available in various sizes and shapes to meet specific application needs.
  • Touch Sensitivity Adjustments: Customizable touch sensitivity settings for different use cases.
  • Interface Options: Offers multiple interface options, including USB, RS232, and I2C.
  • Branding Customization: Custom branding and labeling options to align with your company’s identity.
  • Environmental Enhancements: Options for waterproof, dustproof, and anti-glare features to suit various environments.
10.1 Inch Touch Screen Panel PCAP Interactive Touch Screen Display 2
10.1 Inch Touch Screen Panel PCAP Interactive Touch Screen Display 3
10.1 Inch Touch Screen Panel PCAP Interactive Touch Screen Display 4

Packaging and Shipping

  • Secure Packaging: Each unit is securely packaged to prevent damage during transit.
  • Customized Packaging: Available for tailored packaging solutions to meet specific branding and presentation needs.
  • Reliable Shipping: Efficient and reliable shipping options to ensure timely delivery worldwide.
  • Eco-Friendly Materials: Utilizes environmentally friendly packaging materials to minimize environmental impact.

FAQ

Q: What operating systems is the touch screen panel compatible with?
A: The touch screen panel is compatible with a wide range of operating systems, including Windows, Android, and Linux.

Q: Is the touch screen panel durable for industrial use?
A: Yes, the panel is designed to withstand harsh environments and frequent use, making it ideal for industrial applications.

Q: How can I connect the touch screen panel to my device?
A: The panel offers multiple interface options, including USB, RS232, and I2C, for easy and reliable connectivity.

Q: What is the warranty period for this touch screen panel?
A: The product comes with a standard one-year warranty, with options for extended warranties available.

Q: Can the touch sensitivity be customized?
A: Yes, the touch sensitivity can be adjusted to meet specific user needs and application requirements.

Q: Is technical support available for integration and setup?
A: Yes, comprehensive technical support is available to assist with setup and integration, ensuring smooth implementation into your system.

10.1 Inch Touch Screen Panel PCAP Interactive Touch Screen Display 5
