Custom Prices 15 Inch Touchscreen with Waterproof Design and 2-10 Points Multi Touch

Custom Prices 15 Inch Touchscreen with Waterproof Design and 2-10 Points Multi Touch

15 Inch Touchscreen

2-10 Points Touchscreen

Waterproof Design Touchscreen

Place of Origin:

Guangdong, China

Brand Name:

Finelink

Model Number:

8066 150

Contact Us
Request A Quote
Product Details
Features:
IK10, Waterproof IP65
Application:
Monitor, Touch Monitor, Touch Display, Kiosk, Smart TV, Touch Panel For POS Monitor
Interface:
USB/I2C/Serial Port, I2C/USB/RS232
Type:
Capacitive
Diagonal Screen Size:
15 Inch
Width:
287mm
Drive IC:
EETI/ILIEK/SIS
Product Name:
15 Inch Capacitive Touch Panel
Structure:
Glass+Glass+FPC+IC
Color:
Multi
Solution:
EETI/ILIEK/SIS
Touch Points:
Multi Point Touch
Function:
Multifunctional
OS:
Linux/ Win/Android Optional
HS Code:
85480000
Highlight:

15 Inch Touchscreen

,

2-10 Points Touchscreen

,

Waterproof Design Touchscreen

Payment & Shipping Terms
Minimum Order Quantity
2 pieces
Price
$19.22/pieces 2-99 pieces
Packaging Details
FINELINK Brand 10K Month Capacity 32 Inch G+G EETI/ILITEK Capacitive Touch Panel for Wall-Mount Photo Frame AIO
Standard packaging with carton or wooden box
1.The touch panel packing with foam plastic materials;
2.Packing with carton or wooden box
Delivery Time
7-20 work days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Product Description

Product Description: The custom-priced 15-inch touchscreen with a waterproof design and 2-10 points multi-touch functionality is a versatile touch input solution tailored to meet specific customer needs. It combines advanced touchscreen technology with a waterproof design to provide reliable touch control in various environments.



Item
15 Inch G+G Capacitive Touch Panel
Ratio
4:3
Structure
G+G
Type
Capacitive
Touch controller
EETI/ILITEK
Connection
COB
Lens OD
287*176mm
Sensor OD
270*159mm
Cover glass(T)
3mm
SENSOR(T)
0.7mm
Surface hardness
≥6H
Transmittance
≥85%
Touch points
10 Points
Operating Temperature
-20℃ ~ +60℃
Interface Type
USB, RS232, I2C
Color
Black,White,Transparent,Colors Optional
Customized
AG/AR/AF/AM/AH/Waterproof/Vandalproof/Glove touch
Operating system
WinXP/7/8/10,Android,IOS,Mac,Linux
Application
Industrial,Medical,Banking,Consumer,Education,HMI.....
Warranty
12 Months(3 years maximum)

Product Features:

  • Custom Pricing: Offers flexible pricing options tailored to the specific requirements and budget of customers, ensuring cost-effectiveness and value for money.
  • Waterproof Design: Features a waterproof design that protects the touchscreen from moisture and spills, making it suitable for use in wet or damp environments.
  • 2-10 Points Multi-Touch: Supports 2-10 points multi-touch functionality, allowing for intuitive and responsive touch interactions, such as pinch-to-zoom and multi-finger gestures.
  • High Sensitivity: Provides high sensitivity and accuracy, ensuring precise touch control even in challenging conditions or with gloved hands.
  • Durable Construction: Built with a durable construction to withstand rugged use and harsh environmental conditions, ensuring long-lasting performance and reliability.
  • Versatile Compatibility: Compatible with a wide range of devices and systems, including industrial equipment, kiosks, POS terminals, and more.

Custom Prices 15 Inch Touchscreen with Waterproof Design and 2-10 Points Multi Touch 0

Application Scenarios:

  • Industrial Automation: Integrated into industrial automation systems and machinery for monitoring and controlling processes in manufacturing and production facilities.
  • Outdoor Kiosks: Used in outdoor kiosks and information terminals for public use, providing weather-resistant touch input in parks, transportation hubs, and outdoor venues.
  • Food and Beverage: Deployed in food and beverage environments, such as restaurants and cafes, for touchscreen ordering systems and point-of-sale terminals.
  • Medical Devices: Incorporated into medical devices and equipment interfaces for hygienic touch control and patient monitoring in healthcare facilities.

Custom Prices 15 Inch Touchscreen with Waterproof Design and 2-10 Points Multi Touch 1

Customization Services:

  • Pricing Options: Offers custom pricing options based on specific requirements, volume orders, and budget considerations.
  • Touchscreen Technology: Provides options for different touchscreen technologies (capacitive, resistive, etc.) and touch point configurations (2-10 points) to meet unique application needs.
  • Waterproof Rating: Customizes the waterproof rating and sealing level to ensure suitability for specific environmental conditions and usage scenarios.
Custom Prices 15 Inch Touchscreen with Waterproof Design and 2-10 Points Multi Touch 2
Custom Prices 15 Inch Touchscreen with Waterproof Design and 2-10 Points Multi Touch 3
Custom Prices 15 Inch Touchscreen with Waterproof Design and 2-10 Points Multi Touch 4

Packaging and Shipping:

  • Secure Packaging: Each touchscreen is securely packaged to prevent damage during transportation, ensuring safe delivery to customers.
  • Flexible Shipping Options: Offers flexible shipping options to accommodate varying delivery preferences and timelines, ensuring timely arrival at the desired destination.

FAQ:

  1. What is the waterproof rating of the touchscreen? The waterproof rating of the touchscreen can be customized based on specific requirements, ranging from basic splash resistance to full immersion protection.

  2. Can the touchscreen support simultaneous touch inputs from multiple users? Yes, the touchscreen supports 2-10 points multi-touch functionality, allowing for simultaneous touch inputs from multiple users for collaborative interactions.

  3. Is the touchscreen compatible with different operating systems? Yes, the touchscreen is compatible with various operating systems, including Windows, Linux, and Android, ensuring versatility and ease of integration.

  4. Does the touchscreen require any special installation or setup? No, the touchscreen features plug-and-play installation and does not require any special setup or configuration. Simply connect it to the compatible device or system, and it's ready to use.

  5. Can the touchscreen be customized for specific screen sizes or aspect ratios? Yes, we offer customization services to tailor the touchscreen to fit specific screen sizes, aspect ratios, and dimensions, ensuring seamless integration with existing displays or monitors.

Custom Prices 15 Inch Touchscreen with Waterproof Design and 2-10 Points Multi Touch 5
