Place of Origin:
Guangdong, China
Brand Name:
Finelink
Model Number:
8060 104
Item
|
10.4 Inch G+G Capacitive Touch Panel
|
---|---|
Ratio
|
4:3
|
Structure
|
G+G
|
Type
|
Capacitive
|
Touch controller
|
EETI/ILITEK /SIS
|
Connection
|
COB
|
Lens OD
|
245.1*192.5mm
|
Sensor OD
|
235.2*175.4mm
|
Cover glass(T)
|
3mm
|
SENSOR(T)
|
0.7mm
|
Surface hardness
|
≥6H
|
Transmittance
|
≥85%
|
Touch points
|
10 Points
|
Operating Temperature
|
-20℃ ~ +60℃
|
Interface Type
|
USB, RS232, IIC
|
Color
|
Black,White,Transparent,Colors Optional
|
Customized
|
AG/AR/AF/AM/AH/Waterproof/Vandalproof/Glove touch
|
Operating system
|
WinXP/7/8/10,Android,IOS,Mac,Linux
|
Application
|
Industrial,Medical,Banking,Consumer,Education,HMI.....
|
Warranty
|
12 Months(3 years maximum)
|
Q: Is the touch panel compatible with all versions of Raspberry Pi?
A: Yes, the touch panel is designed to be compatible with all versions of Raspberry Pi, providing seamless integration and functionality.
Q: What type of touch technology is used in this panel?
A: The touch panel uses projected capacitive (PCAP) technology, known for its accuracy and multi-touch capabilities.
Q: How does the waterproofing impact the touch performance?
A: The IP65-rated waterproofing ensures reliable touch performance even in wet conditions without compromising sensitivity or accuracy.
Q: Can this touch panel be used in extreme temperatures?
A: Yes, the touch panel is designed to operate effectively in a wide range of temperatures, suitable for various industrial and outdoor environments.
Q: Is there a need for additional drivers to use this touch panel with Raspberry Pi?
A: The touch panel is plug-and-play with Raspberry Pi, though specific drivers or software may be required depending on the operating system and application.
Q: Can the touch panel be calibrated for different touch sensitivity levels?
A: Yes, the touch sensitivity can be adjusted and calibrated through software settings or the provided calibration tools to meet specific user preferences and requirements.
